5-Ton Extruded Soybean Production Line

Raw material pre-treatment: After the soybeans are sorted, they are crushed by a double-roller crusher into 4-6 pieces, and then crushed by a hammer-type grinder (with a sieve aperture of 1.6-2.0mm). A dust-proof and oil-proof dust removal system is used to prevent the material from sticking.

Steam conditioning: The ground materials are fed into the double-layer conditioning machine, where they are mixed and matured by steam. The outlet temperature is controlled at 96-102℃, and the moisture content is ≤14.7%. This prepares for the extrusion process. High-temperature extrusion: After quenching, the material is sent into the extruder. It is extruded under high temperature (125-135℃) and high pressure conditions. The diameter of the discharge mold hole is 8-10mm. The urease activity of the finished product is 0.02-0.03, and the protein solubility is 70%-80%.

Cooling and Drying: The expanded materials are processed through a counter-flow plate cooler. The negative pressure drying process ensures that the outlet material temperature is ≤ ambient temperature + 8℃ and the moisture content is ≤ 12%, preventing spoilage and mold growth.

Finished product processing: After cooling, the materials are crushed by the finished product crusher to ensure that the over-screening rate of the 20-mesh sieve is ≥ 90% (customizable to 98%). Finally, the finished products are completed through measurement, weighing, and packaging.

Send Email Inquiry Now

Product Introduction

1. 6000 square meter self-built extrusion equipment factory, source factory of soybean extrusion machines

2. Core technology independently developed, efficiency of extrusion units increased by 20%, energy consumption reduced by 15%

3. The company's business covers more than 20 countries around the world, meeting the needs of multiple scenarios such as breeding, feed processing, and oil production

4. Full-cycle services covering process design, equipment installation, commissioning and optimization

Product Advantages

Product parameters of Dollar Soybean Puffing Machine:

The bearing box is integrally cast and forged, which increases the weight by approximately 100 kilograms compared to similar products on the market!
The motor is a first-class brand from Siemens, which is durable and has strong power!
The bearings are of the German imported FAG (Schaeffler) brand, with an average lifespan that is 2-3 years longer than those made in China!
Technologies such as quantitative water injection, oil and lubricant water cooling heat exchange, automatic alarm, and double sealing of the bearing chamber reduce the failure rate of the machine!

Shipping And After Sales

Choose reliable logistics

1. Co-operation with excellent carriers: By cooperating with world-renowned logistics partners, we provide high-quality logistics services with full traceability to ensure timely and accurate delivery around the world.

2. Full tracking: We are committed to safe and efficient packaging methods to ensure the integrity of the equipment during long-distance transportation.

Arrival and acceptance guide

1. Unpacking guide: Detailed unpacking and inspection tips are attached with the shipment, instructing customers how to open the package safely and check the condition of the excavator.

2. After-sales service: Provide 24-hour online technical assistance to ensure that subsequent problems can be solved in a timely manner.
